Submersible dewatering pump, small (up to 20 m³/h)
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Centrifugal Pump
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-0396 |
| Category | Pumps |
| Group | Pumps |
| Brand | Grundfos |
| Available / equivalent brands | Grundfos, KSB, Ebara, Wilo, Kirloskar |
| Technical | |
| Type | Centrifugal Pump |
Datasheet
Design standard
| Motor to IEC 60034, IP68 |
Technical features
| Pump and motor in one sealed unit that works fully submerged | |
| Portable, with a lifting handle and hose connection; float switch option for automatic operation | |
| Wear-resistant impeller and diffuser for water with sand and silt | |
| Used for construction sites, basements, pits, flood relief and mining |
Typical specification (product type)
| Flow | 5–500 m³/h (series dependent) |
|---|---|
| Head | 5–60 m |
| Solids passage | up to 10 mm typical |
| Motor protection | IP68, thermal protection in the windings |
| Supply | 1-ph 230 V or 3-ph 400 V |
Notes
| Check maximum submergence depth and allowable sand content. | |
| Typical values for this product type; the exact rating, size and materials are confirmed in Argonmark's quotation for the selected make and model. | |
| Illustrative photo of the product type | PumpExpert, CC BY-SA 4.0, via Wikimedia Commons (background removed). |
|---|---|
Photo: PumpExpert, CC BY-SA 4.0, via Wikimedia Commons — illustrative photo of the product type, edited by Argonmark. All photo credits
Description
Submersible dewatering pump. Pump and motor in one sealed unit that works fully submerged. Portable, with a lifting handle and hose connection; float switch option for automatic operation. Wear-resistant impeller and diffuser for water with sand and silt.
Argonmark Ltd supplies this item to factories, power plants, utilities, contractors and government projects across Bangladesh. Send us the required size, rating, materials and quantity and we will reply with a quotation within 24 hours.
