WIKA CPB3500 pneumatic dead-weight tester, −1 to 120 bar
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Calibration equipment
- Hazardous area: General purpose
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-1424 |
| Category | Oil & Gas Instruments |
| Group | Instrumentation & Control |
| Brand | WIKA |
| Model | CPB3500 |
| Technical | |
| Type | Calibration equipment |
| Hazardous area | General purpose |
Datasheet
Technical features
| Genuine primary standard | pressure derived directly from p = F/A |
|---|---|
| Five interchangeable piston-cylinder systems: ±1, 0.1–7, 0.2–25, 1–70, 1–120 bar (psi and kPa versions) | |
| Two precision soft-seat valves and a volume adjuster for fine pressure control | |
| Stable aluminium base with impact-resistant ABS cover; complete stand-alone system | |
| Non-magnetic stainless steel mass sets, interchangeable between pistons of the same range | |
| Factory calibration traceable to national standards; UKAS calibration optional | |
Applications
| Primary standard in factory and calibration laboratories | |
| On-site calibration of pressure gauges, transmitters and switches |
Key specifications
| Pressure range | −1 to 120 bar (five piston-cylinder systems) |
|---|---|
| Accuracy | 0.015% of reading (premium 0.008–0.006%) |
| Medium | Clean, dry, non-corrosive gas (air, nitrogen) |
| Test connection | G ½ female, loose union (adapters G ¼, G ⅜) |
| Use | Primary pressure standard, lab and on site |
Specification
| Accuracy, standard | 0.015% of reading (from 10% of range; down to 0.02% without area correction) |
|---|---|
| Accuracy, premium | 0.008% (1 bar) / 0.006% of reading, with UKAS area and mass certificates |
| psi versions | 1–100, 3–400, 15–1,000, 10–1,600 psi |
| kPa versions | 1.5–100 up to 100–12,000 kPa |
| Mass set | Non-magnetic stainless steel, standard gravity 9.80665 m/s² (local gravity optional) |
| Piston-cylinder connection | G 1 female |
| Test item connection | G ½ female, loose union, adapters to G ¼ and G ⅜ |
| External pressure connection | G ¼ female (¼ NPT adapter supplied) |
| Operating temperature | 10 to 30 °C |
| Base | 510 × 490 × 300 mm, 12 kg |
| Calibration | Factory certificate; UKAS (area and mass) optional |
Piston-cylinder systems
| Measuring range | Required masses | Smallest step (standard / fine masses) | Piston effective area | Piston / cylinder |
|---|---|---|---|---|
| 0.015 to 1 bar (vacuum adapter for −1 bar) | 3.3 kg | 0.005 bar / – | ½ in² | High-chromium steel / high-chromium steel |
| 0.1 to 7 bar | 22.5 kg | 0.05 / 0.005 bar | ½ in² | High-chromium steel / high-chromium steel |
| 0.2 to 25 bar | 21 kg | 0.3 / 0.01 bar | ⅛ in² | Tungsten carbide / tungsten carbide |
| 1 to 70 bar | 29 kg | 0.5 / 0.02 bar | 1/16 in² | High-chromium steel / bronze |
| 1 to 120 bar | 49.5 kg | 0.5 / 0.02 bar | 1/16 in² | High-chromium steel / bronze |
Notes
| Data from the manufacturer's published datasheet. Confirm model, range, materials and approvals with Argonmark before ordering. |
Photo: courtesy of WIKA, used with permission (source) — background removed by Argonmark. All photo credits
Description
The WIKA CPB3500 is a pneumatic dead-weight tester: a primary pressure standard that generates pressure directly from mass and piston area (p = F/A). Five interchangeable piston-cylinder systems cover vacuum to 1 bar, 0.1–7, 0.2–25, 1–70 and 1–120 bar (or psi/kPa equivalents) with an accuracy of 0.015% of reading, or down to 0.006% in the premium version with UKAS certificates.
Two precision valves and a volume adjuster set each point, the mass sets are non-magnetic stainless steel, and the aluminium base with ABS cover is robust enough for site work as well as the laboratory.
Argonmark Ltd supplies WIKA instruments across Bangladesh — Dhaka, Chattogram, Gazipur, Narayanganj and the gas fields, refineries, terminals and power plants beyond. Send us the model, range, process connection, output and any hazardous-area requirement, and we will confirm the right configuration, lead time and price.
