Isotech Calisto 4953 multifunction temperature calibrator (dry block / liquid bath), 30 to 250 °C
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Calibration equipment
- Signal / Protocol: USB
- Hazardous area: General purpose
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-1437 |
| Category | Oil & Gas Instruments |
| Group | Instrumentation & Control |
| Brand | Isotech |
| Model | Calisto 4953 (Isocal-6) |
| Technical | |
| Type | Calibration equipment |
| Signal / Protocol | USB |
| Hazardous area | General purpose |
Datasheet
Technical features
| Six modes | dry block, stirred liquid bath, surface sensor, infrared blackbody and ITS-90 fixed point accessories |
|---|---|
| Calibrates the whole measurement loop | |
| Advanced version | inputs for reference and test thermometers, automatic cycling, secure data logging, web server, colour display |
| Site version | built-in independent indicator for a reference probe |
| Meets EURAMET cg-13 calibration capacity requirements; I-Cal Easy LOG software included | |
Applications
| Calibration of RTDs, thermocouples, thermometers and temperature loops | |
| Surface and infrared thermometer checks with accessories |
General
| Calibration volume | 35 mm × 160 mm |
|---|---|
| Standard insert | 6 pockets: 2 × 4.5, 2 × 6.4, 1 × 8.0, 1 × 9.5 mm, all 157 mm deep |
| Dimensions | 384 H × 212 W × 312 D mm |
| Power | 300 W, 115 or 230 V AC 50/60 Hz |
| Weight | 8 kg |
Key specifications
| Temperature range | 30 to 250 °C (in 20 °C ambient) |
|---|---|
| Stability | ±0.03 °C (Basic/Site); ±0.02 °C (Advanced) |
| Display accuracy | 0.25 °C (dry block, 4.5 mm well) |
| Calibration volume | 35 × 160 mm, 6-pocket standard insert |
| Versions | Basic, Site (reference indicator), Advanced (logging, cycling) |
| Power | 300 W, 115 or 230 V AC |
Performance
| Temperature range | 30 to 250 °C (20 °C ambient) |
|---|---|
| Stability (Advanced) | ±0.02 °C dry block / liquid bath |
| Stability (Basic/Site) | ±0.03 °C |
| Display resolution | 0.01 °C |
| Display accuracy | 0.25 °C (dry block mode) |
| Uniformity between wells (dry block) | < 0.02 °C at 250 °C |
| Axial uniformity, lower 40 mm | < 0.25 °C dry block; < 0.02 °C liquid bath at 250 °C |
| Heating / cooling | 25 → 250 °C in 15 min; 250 → 30 °C in 25 min |
| Other modes | Blackbody ±0.3 °C; surface sensor ±0.5 °C; ITS-90 cells ±0.0005 °C |
Advanced input channels
| RTD input | ±0.005% of reading |
|---|---|
| Thermocouple input | E, J, K, N ±0.2 °C at 660 °C; R ±0.6 °C; S ±0.7 °C; T ±0.2 °C at 150 °C |
| CJC accuracy | ±0.35 °C |
| Interface | Ethernet + USB host (Basic/Site: serial) |
Notes
| Data from the manufacturer's published datasheet. Confirm model, range, materials and approvals with Argonmark before ordering. |
Photo: courtesy of Isotech, used with permission (source) — background removed by Argonmark. All photo credits
Description
The Isotech Calisto 4953 is a multifunction temperature calibrator for 30 °C to 250 °C that works as a dry block or, with accessories, as a stirred liquid bath, surface-sensor calibrator, infrared blackbody or ITS-90 fixed-point system. Its 35 × 160 mm calibration volume takes a six-pocket insert, with stability of ±0.03 °C (±0.02 °C in the Advanced version).
The Basic version shows set and block temperature, the Site adds a reference-probe indicator, and the Advanced adds test-thermometer inputs, automatic cycling and secure data logging, so a whole measurement loop can be calibrated in the field.
Argonmark Ltd supplies Isotech instruments across Bangladesh — Dhaka, Chattogram, Gazipur, Narayanganj and the gas fields, refineries, terminals and power plants beyond. Send us the model, range, process connection, output and any hazardous-area requirement, and we will confirm the right configuration, lead time and price.
