Isotech Europa 4520 multifunction temperature calibrator (dry block / liquid bath), −45 to 140 °C
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Calibration equipment
- Signal / Protocol: USB
- Hazardous area: General purpose
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-1438 |
| Category | Oil & Gas Instruments |
| Group | Instrumentation & Control |
| Brand | Isotech |
| Model | Europa 4520 (Isocal-6) |
| Technical | |
| Type | Calibration equipment |
| Signal / Protocol | USB |
| Hazardous area | General purpose |
Datasheet
Technical features
| Sub-zero calibrator | six modes including dry block and stirred liquid bath |
|---|---|
| Accessories for surface sensors, infrared thermometers and ITS-90 fixed points | |
| Advanced version | reference and test inputs, automatic cycling, tamper-proof data logging, web server |
| Site version | independent reference-probe indicator |
| Meets EURAMET cg-13; I-Cal Easy LOG software included | |
Applications
| Calibration of temperature sensors and loops below and above ambient | |
| Field and laboratory temperature calibration |
General
| Calibration volume | 35 mm × 160 mm |
|---|---|
| Standard insert | 6 pockets: 2 × 4.5, 2 × 6.4, 1 × 8.0, 1 × 9.5 mm, all 157 mm deep |
| Dimensions | 384 H × 212 W × 312 D mm |
| Power | 300 W, 115 or 230 V AC 50/60 Hz |
| Weight | 14 kg |
Key specifications
| Temperature range | −45 to 140 °C (65 °C below ambient; absolute min. −55 °C) |
|---|---|
| Stability | ±0.03 °C (Basic/Site); ±0.01 °C (Advanced) |
| Display accuracy | 0.15 °C (dry block, 4.5 mm well) |
| Calibration volume | 35 × 160 mm, 6-pocket standard insert |
| Versions | Basic, Site (reference indicator), Advanced (logging, cycling) |
| Power | 300 W, 115 or 230 V AC |
Performance
| Temperature range | −45 to 140 °C (min. 65 °C below ambient; absolute −55 °C) |
|---|---|
| Stability (Advanced) | ±0.01 °C dry block / liquid bath |
| Stability (Basic/Site) | ±0.03 °C |
| Display resolution | 0.001 °C (Advanced) |
| Display accuracy | 0.15 °C (dry block mode) |
| Uniformity between wells (dry block) | < 0.008 °C |
| Axial uniformity, lower 40 mm | < 0.040 °C dry block; < 0.026 °C liquid bath |
| Heating / cooling | −30 → 140 °C in 15 min; 140 → 0 °C in 15 min |
| Other modes | Blackbody ±0.3 °C; surface sensor ±0.5 °C; ITS-90 cells ±0.0005 °C |
Advanced input channels
| RTD input | ±0.005% of reading |
|---|---|
| Thermocouple input | E, J, K, N ±0.2 °C at 660 °C; R ±0.6 °C; S ±0.7 °C; T ±0.2 °C at 150 °C |
| CJC accuracy | ±0.35 °C |
| Interface | Ethernet + USB host (Basic/Site: serial) |
Notes
| Data from the manufacturer's published datasheet. Confirm model, range, materials and approvals with Argonmark before ordering. |
Photo: courtesy of Isotech, used with permission (source) — background removed by Argonmark. All photo credits
Description
The Isotech Europa 4520 is a multifunction temperature calibrator for −45 °C to 140 °C, usable as a dry block or stirred liquid bath and, with accessories, for surface sensors, infrared thermometers and ITS-90 fixed points. It offers ±0.03 °C stability (±0.01 °C in the Advanced version) and excellent uniformity between wells (< 0.008 °C).
Basic, Site and Advanced versions range from a simple set-and-read unit to one with reference and test thermometer inputs, automatic cycling and secure logging, all in a 14 kg portable case.
Argonmark Ltd supplies Isotech instruments across Bangladesh — Dhaka, Chattogram, Gazipur, Narayanganj and the gas fields, refineries, terminals and power plants beyond. Send us the model, range, process connection, output and any hazardous-area requirement, and we will confirm the right configuration, lead time and price.
