Isotech QuickCal 550 hand-held temperature test unit, 30 to 350 °C
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Calibration equipment
- Hazardous area: General purpose
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-1443 |
| Category | Oil & Gas Instruments |
| Group | Instrumentation & Control |
| Brand | Isotech |
| Model | QuickCal-550 |
| Technical | |
| Type | Calibration equipment |
| Hazardous area | General purpose |
Datasheet
Technical features
| Light, compact hand-held unit for less-exacting temperature checks | |
| Interchangeable inserts for different sensor diameters (blank and special drillings available) | |
| 9 minutes from ambient to 350 °C | |
| Supplied with 5-pocket insert |
Applications
| Quick site checks of temperature sensors, thermostats and gauges |
Key specifications
| Temperature range | 30 to 350 °C (20 °C ambient) |
|---|---|
| Stability | ±0.1 °C |
| Accuracy | ±0.2 to ±0.4 °C by comparison; ±0.4 °C (< 100 °C) / ±1.5 °C (> 100 °C) against display |
| Calibration volume | 25 mm Ø × 120 mm, interchangeable inserts |
| Weight | 1.5 kg |
| Power | 110 V AC ±10% |
Specification
| Temperature range | +30 to +350 °C in 20 °C ambient |
|---|---|
| Set point resolution | 0.1 °C |
| Accuracy by comparison | ±0.2 to ±0.4 °C |
| Accuracy vs display | ±0.4 °C below 100 °C; ±1.5 °C above 100 °C (single probe in 6.8 mm sleeve) |
| Stability | ±0.1 °C |
| Time to set point | 9 min ambient → 350 °C; plus ~5 min for best stability |
| Calibration volume | 25 mm Ø × 120 mm deep |
| Standard insert | 5 pockets: 8, 6.5, 6.5, 4.5, 4.5 mm, 115 mm deep |
| Power | 110 V AC ±10%, 50/60 Hz |
| Dimensions | 65 × 152 × 175 mm (H × W × D) |
| Weight | 1.5 kg |
| Accessories | Standard and blank inserts, carry case, semi-standard PRT 935-14-98, °F version |
Notes
| Data from the manufacturer's published datasheet. Confirm model, range, materials and approvals with Argonmark before ordering. |
Photo: courtesy of Isotech, used with permission (source) — background removed by Argonmark. All photo credits
Description
The Isotech QuickCal 550 is a compact hand-held temperature test unit for 30 °C to 350 °C, for quick checks where a full laboratory calibrator is not needed. It weighs only 1.5 kg, reaches 350 °C in about nine minutes, holds ±0.1 °C stability and accepts interchangeable 25 mm inserts for different sensor diameters.
Used with a reference probe it achieves ±0.2–0.4 °C by comparison.
Argonmark Ltd supplies Isotech instruments across Bangladesh — Dhaka, Chattogram, Gazipur, Narayanganj and the gas fields, refineries, terminals and power plants beyond. Send us the model, range, process connection, output and any hazardous-area requirement, and we will confirm the right configuration, lead time and price.
