Isotech 550-02 QuickCal blackbody source for infrared thermometers, 30 to 350 °C
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Calibration equipment
- Hazardous area: General purpose
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-1457 |
| Category | Oil & Gas Instruments |
| Group | Instrumentation & Control |
| Brand | Isotech |
| Model | 550-02 QuickCal Blackbody (and 975 Greybody) |
| Technical | |
| Type | Calibration equipment |
| Hazardous area | General purpose |
Datasheet
Technical features
| Low-cost, very portable source for rapid checks of infrared thermometers | |
| Cavity with end cone gives overall emissivity above 0.99 (suits ε 0.99 or adjustable-emissivity thermometers) | |
| Control sensor just under the target surface; NIST-traceable certificate supplied | |
| Companion Model 975 greybody | 70 mm flat target, ε > 0.95, 50–350 °C, ±2 °C, for fixed-emissivity (0.95) thermometers |
|---|---|
| °C or °F operation | |
Applications
| Quick field checks and calibration of handheld infrared thermometers |
Key specifications
| Temperature range | 30 to 350 °C |
|---|---|
| Accuracy | ±1 °C |
| Stability | ±0.5 °C |
| Emissivity | > 0.99 (cavity with end cone) |
| Target | 25 × 115 mm cavity |
| Weight | 1.5 kg |
Models
| Parameter | 550-02 QuickCal blackbody | 975 greybody |
|---|---|---|
| Temperature range | 30 to 350 °C | 50 to 350 °C |
| Accuracy | ±1 °C | ±2 °C |
| Stability | ±0.5 °C | ±0.5 °C |
| Display resolution | 0.1 °C | 0.1 °C |
| Time to temperature | 9 min | 35 min |
| Target | 25 × 115 mm cavity with end cone | 70 mm diameter flat |
| Emissivity | > 0.99 | > 0.95 |
| Power | 300 W, 110 V AC ±10% | 180 W, 110 V AC ±10% |
| Dimensions (H × W × D) | 65 × 152 × 175 mm | 115 × 230 × 225 mm |
| Weight | 1.5 kg | 3.9 kg |
Notes
| Data from the manufacturer's published datasheet. Confirm model, range, materials and approvals with Argonmark before ordering. |
Photo: courtesy of Isotech, used with permission (source) — background removed by Argonmark. All photo credits
Description
The Isotech 550-02 QuickCal is a compact, low-cost blackbody source for quick checks of infrared thermometers from 30 °C to 350 °C. Its 25 × 115 mm cavity with an end cone gives an emissivity above 0.99, with ±1 °C accuracy and ±0.5 °C stability, and it reaches temperature in about nine minutes.
The matching Model 975 greybody offers a 70 mm flat target (ε > 0.95) for fixed-emissivity thermometers. Both come with a NIST-traceable certificate and weigh only a few kilograms.
Argonmark Ltd supplies Isotech instruments across Bangladesh — Dhaka, Chattogram, Gazipur, Narayanganj and the gas fields, refineries, terminals and power plants beyond. Send us the model, range, process connection, output and any hazardous-area requirement, and we will confirm the right configuration, lead time and price.
