MTL 949X intrinsically safe isolated power supplies, 24 V DC in, Ex ia / Ex ib outputs 4.8 to 17.7 V
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Power supplies & barriers
- Hazardous area: Hazardous-area rated / option
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-1507 |
| Category | Oil & Gas Instruments |
| Group | Instrumentation & Control |
| Brand | MTL |
| Model | 9491-PS, 9492-PS-PLUS, 9493-PS-xxx |
| Technical | |
| Type | Power supplies & barriers |
| Hazardous area | Hazardous-area rated / option |
Datasheet
Technical features
| Isolated supply producing an intrinsically safe output to power instruments in Zone 0/1 hazardous areas | |
| Module itself may be mounted in the safe area or Zone 2 (9491 also Division 2) | |
| Internal current limiting with electronic auto-reset circuit breaker on short circuit or overload | |
| LED indication for input power and IS output | |
| Several modules ganged on a 24 V DC distribution backplane for multiple outputs | |
| 9491/9492 power the MTL 9460-ET intrinsically safe Ethernet modules; Power over Ethernet option | |
| ATEX / IECEx certified (9491 also FM / FMC) |
Applications
| Powering instruments, displays and Ethernet modules located in Zone 0/1 hazardous areas | |
| Oil and gas, petrochemical and offshore control systems |
General
| Input | 24 V DC (20–30 V); fuse and reverse-polarity diode |
|---|---|
| Connections | Screw terminals 2.5 mm² (DIN rail) or multipin backplane connector; two IS output connectors |
| Isolation | Um = 253 V rms |
| Humidity | 5–95% RH non-condensing |
| Storage temperature | −20 to +70 °C (9491); −40 to +70 °C (9492, 9493) |
| Weight | 130 g |
| Enclosure | Select to suit the application (see certificate) |
Key specifications
| Input | 24 V DC (20–30 V) |
|---|---|
| Output | Ex ia or Ex ib, 4.8 V to 17.7 V depending on model |
| Gas groups | IIB or IIC (9493: Group I, IIA, IIB or IIC) |
| Mounting | DIN rail or power distribution backplane; safe area or Zone 2 |
| Isolation | Um = 253 V rms input to output |
| Operating temperature | 0 to +70 °C (9491); −40 to +70 °C (9492, 9493) |
9491-PS (12 V)
| Output | 200 mA at 10.9 V DC Ex ia IIB (Zone 0 / Class I Div 1 Groups C, D); 400 mA at 11.8 V DC Ex ib IIB (Zone 1) |
|---|---|
| Input current | 350 mA at 24 V |
| Operating temperature | 0 to +70 °C |
9492-PS-PLUS (12 V)
| Output | 480 mA at 10.0 V DC Ex ia IIB; 550 mA at 11.9 V DC Ex ib IIB |
|---|---|
| Input current | 390 mA at 24 V |
| Operating temperature | −40 to +70 °C |
9493-PS general-purpose models (Ex ia)
| Model | Gas group | Uo | Nominal output voltage | Nominal current (max.) |
|---|---|---|---|---|
| 9493-PS-B5 | IIB | 5.4 V | 4.8–5.2 V | 250 mA (550 mA) |
| 9493-PS-C5 | IIC | 5.4 V | 4.8–5.2 V | 180 mA (550 mA) |
| 9493-PS-C6 | IIC | 7 V | 5.7–6.7 V | 300 mA (550 mA) |
| 9493-PS-C9 | IIC | 10 V | 8.4–9.7 V | 300 mA (550 mA) |
| 9493-PS-C11 | IIC | 12 V | 9.9–11.7 V | 300 mA (550 mA) |
| 9493-PS-C12 | IIC | 13 V | 10.8–12.7 V | 250 mA (260 mA) |
| 9493-PS-B14 | IIB | 15 V | 12.4–14.7 V | 250 mA (260 mA) |
| 9493-PS-C14 | IIC | 15 V | 12.4–14.7 V | 120 mA (260 mA) |
| 9493-PS-B17 | IIB | 18 V | 15.0–17.7 V | 160 mA (260 mA) |
| 9493-PS-C17 | IIC | 18 V | 15.0–17.7 V | 60 mA (160 mA) |
Notes
| Data from the manufacturer's published datasheet. Confirm model, range, materials and approvals with Argonmark before ordering. |
Photo: courtesy of MTL, used with permission (source) — background removed by Argonmark. All photo credits
Description
The MTL 949X are isolated intrinsically safe power supplies that take a 24 V DC supply in the safe area or Zone 2 and deliver an Ex ia or Ex ib output to power equipment in Zone 0 or Zone 1. The 9491-PS and 9492-PS-PLUS give a nominal 12 V output (up to 550 mA Ex ib IIB) for MTL intrinsically safe Ethernet modules, while the 9493-PS range offers Ex ia outputs from 4.8 V to 17.7 V for gas groups IIB or IIC.
Each module has current limiting with an auto-reset electronic breaker, LED status indication and 253 V input-to-output isolation. Modules mount on DIN rail or a backplane and can be ganged for multiple outputs, with ATEX and IECEx certification.
Argonmark Ltd supplies MTL instruments across Bangladesh — Dhaka, Chattogram, Gazipur, Narayanganj and the gas fields, refineries, terminals and power plants beyond. Send us the model, range, process connection, output and any hazardous-area requirement, and we will confirm the right configuration, lead time and price.
