Keller LEO5 high-resolution digital manometer, 0.05% FS, data logger, 1 kHz peak, stainless steel, −1…1 to 0…1,000 bar
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Level
- Signal / Protocol: USB
- Hazardous area: General purpose
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-1526 |
| Category | Oil & Gas Instruments |
| Group | Instrumentation & Control |
| Brand | Keller |
| Model | LEO5 |
| Technical | |
| Type | Level |
| Signal / Protocol | USB |
| Hazardous area | General purpose |
Datasheet
Technical features
| High-resolution reference gauge with large backlit display and bar graph | |
| Pressure peak detection at 1 kHz sampling | |
| Data logger with interval or event-controlled recording; temperature display | |
| Capacitive touch keys; min/max; 14 standard units plus 5 user units | |
| Watertight stainless steel housing with safety glass front | |
| USB connection and free Keller software |
Applications
| Pressure testing and leak tests | |
| Calibration reference for gauges and transmitters | |
| Laboratory and industrial measurement |
Mechanical
| Wetted materials | 316L stainless steel; FKM seals |
|---|---|
| Housing | Stainless steel AISI 304; LEXAN front |
| Connection | G¼ male (others optional) |
| Medium / ambient temperature | −40…85 °C / −10…60 °C |
| Protection | IP65 |
| Size / weight | ≈ 82 × 135 × 40 mm; ≈ 430 g |
Key specifications
| Ranges | −1…1 bar to 0…1,000 bar (relative or absolute) |
|---|---|
| Accuracy | ±0.05% FS; total error band ±0.1% FS (0–50 °C) |
| Resolution | Down to 0.0001 bar |
| Logging | ≥ 56,000 values with timestamp; peak mode 1 kHz |
| Power | Li-ion 4.2 V rechargeable via USB, up to 2,000 h |
| Housing | Stainless steel AISI 304, IP65 |
Performance
| Accuracy at 20–25 °C | ≤ ±0.05% FS |
|---|---|
| Total error band (0–50 °C) | ≤ ±0.1% FS |
| Long-term stability | ≤ ±0.1% FS per year |
| Temperature measurement | ±1 °C typ. |
| Range reserve | ±10% |
| Measuring rate | 2/s standard; 1,000/s peak mode (reduced resolution) |
Electrical and display
| Battery | Li-ion 4.2 V / 2.3 Ah, USB charging; up to 2,000 h (160 h in peak mode); > 300 cycles |
|---|---|
| Interface | Mini USB-B (Keller protocol), 2/s |
| Data logger | ≥ 56,000 values; interval ≥ 1 s, or event-controlled |
| Display | 51.3 × 38.8 mm, 2 rows × 5 digits + bar graph; pressure + min/max or temperature |
| Units | bar, mbar, Pa, hPa, kPa, MPa, psi, mH2O, cmH2O, inH2O, ftH2O, mmHg, inHg, kp/cm² + 5 user units |
Ranges
| Relative (bar) | Absolute (bar abs.) | Overload (bar) | Resolution (bar) |
|---|---|---|---|
| −1…1 | 0…2 | 8 | 0.0001 |
| −1…3 | 0…4 | 8 | 0.0001 |
| −1…6 | 0…7 | 20 | 0.0001 |
| −1…10 | 0…11 | 20 | 0.0001 |
| −1…16 | 0…17 | 40 | 0.001 |
| −1…30 | 0…31 | 60 | 0.001 |
| – | 0…61 | 200 | 0.001 |
| – | 0…101 | 200 | 0.001 |
| – | 0…161 | 300 | 0.01 |
| – | 0…300 | 600 | 0.01 |
| – | 0…400 | 800 | 0.02 |
| – | 0…700 | 1,100 | 0.05 |
| – | 0…1,000 | 1,100 | 0.1 |
Notes
| Data from the manufacturer's published datasheet. Confirm model, range, materials and approvals with Argonmark before ordering. |
Photo: courtesy of Keller, used with permission (source) — background removed by Argonmark. All photo credits
Description
The Keller LEO5 is a high-resolution digital manometer with ±0.05% FS accuracy (±0.1% FS total error band from 0 to 50 °C), available from −1…1 bar to 0…1,000 bar with resolution down to 0.0001 bar. It combines a data logger of 56,000 time-stamped readings with 1 kHz pressure-peak detection, temperature display and a bar graph on a large backlit screen.
Its watertight stainless steel housing has a safety-glass front and capacitive touch keys, and the built-in Li-ion battery lasts up to 2,000 hours and charges over USB. It suits pressure testing, calibration and laboratory work.
Argonmark Ltd supplies Keller instruments across Bangladesh — Dhaka, Chattogram, Gazipur, Narayanganj and the gas fields, refineries, terminals and power plants beyond. Send us the model, range, process connection, output and any hazardous-area requirement, and we will confirm the right configuration, lead time and price.
