Core Sensors CS60 explosion-proof pressure transducer, 50 to 30,000 psi (3.4 to 2,070 bar)
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Pressure transmitters
- Signal / Protocol: 4–20 mA, Voltage
- Hazardous area: Hazardous-area rated / option
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-1538 |
| Category | Oil & Gas Instruments |
| Group | Instrumentation & Control |
| Brand | Core Sensors |
| Model | CS60 |
| Technical | |
| Type | Pressure transmitters |
| Signal / Protocol | 4–20 mA, Voltage |
| Hazardous area | Hazardous-area rated / option |
Datasheet
Technical features
| Rated for Class I, Division 1 / Zone 1 (explosion-proof) hazardous locations | |
| All-welded stainless steel construction | |
| 4–20 mA or 1–5 V output | |
| Overpressure 2 × minimum; 100 million pressure cycles; 1-year stability ≤ ±0.25% FS | |
| Configurable process and electrical connections |
Applications
| Pipeline equipment | |
| Oil and gas production in Class I Div 1 / Zone 1 areas | |
| Hydrogen and natural gas compression |
Environment and construction
| Thermal effects | TC zero and TC span ≤ ±1% FS (≤ ±2% FS at 2 psi and below) |
|---|---|
| Wetted materials | Stainless steel, one-piece diaphragm, factory-sealed welded case |
| Process connections | ½ NPT M, ¼ NPT M and others; ½ in MNPT conduit electrical |
| Electrical connections | DIN 43650-A, Turck Minifast, ½ in MNPT conduit with cable, M12, bayonet (varies by model) |
| Approvals | CSA Class I Div 1 Groups A–D T4; Class I Zone 1 AEx db IIC T4 Gb / Ex db IIC T4 Gb; dust ignition-proof Class II Div 1 E–G, Zone 21 Ex tb IIIC T135 °C Db; ANSI/UL 122701 single seal; CE |
Key specifications
| Range | 50 to 30,000 psi (3.4 to 2,070 bar) |
|---|---|
| Accuracy | ≤ ±0.25% BFSL (≤ ±0.5% above 10,000 psi) |
| Outputs | 4–20 mA, 1–5 V |
| Supply | 10–28 V DC (5 V ratiometric; 3–5 V low power) |
| Wetted materials | Stainless steel, one-piece diaphragm, factory-sealed welded case |
| Approvals | CSA Class I Div 1 Groups A–D T4 |
Performance
| Range | 50 to 30,000 psi (3.4 to 2,070 bar) |
|---|---|
| Accuracy at 25 °C (non-linearity, hysteresis, repeatability) | ≤ ±0.25% BFSL (≤ ±0.5% above 10,000 psi) |
| Stability (1 year) | ≤ ±0.25% FS |
| Pressure cycles | 100 million |
| Overpressure | 2 × minimum |
| Burst pressure | 5 × or 60,000 psi, whichever is less |
| Thermal (CS60) | Operating −40 to +85 °C; media −40 to +120 °C; compensated −15 to +65 °C; IP66 |
Electrical
| Outputs | 4–20 mA, 1–5 V |
|---|---|
| 4–20 mA | Excitation 10–28 V DC; load 0–800 Ω; ≈ 250 Hz response; 20 mA typical |
| 1–5 V / 1–6 V | Excitation 10–28 V DC; < 10 mA; load ≥ 5 kΩ; ≈ 1 kHz |
| Zero offset / span tolerance | ±0.5% FS typical, ±1% max |
Notes
| Data from the manufacturer's published datasheet. Confirm model, range, materials and approvals with Argonmark before ordering. |
Photo: courtesy of Core Sensors, used with permission (source) — background removed by Argonmark. All photo credits
Description
The Core Sensors CS60 is an explosion-proof pressure transducer for Class I, Division 1 / Zone 1 (explosion-proof) locations, covering 50 to 30,000 psi (3.4 to 2,070 bar) with ≤ ±0.25% BFSL accuracy. Its all-welded stainless steel construction withstands 2 × overpressure and 100 million pressure cycles, with drift of no more than 0.25% FS per year.
Outputs include 4–20 mA, 1–5 V, and process and electrical connections can be configured to suit the installation. Approvals: CSA Class I Div 1 Groups A–D T4.
Argonmark Ltd supplies Core Sensors instruments across Bangladesh — Dhaka, Chattogram, Gazipur, Narayanganj and the gas fields, refineries, terminals and power plants beyond. Send us the model, range, process connection, output and any hazardous-area requirement, and we will confirm the right configuration, lead time and price.
