Portable shaker table 9100D for field checking accelerometers, velocity sensors and proximity probes, 7 Hz–10 kHz
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Calibration equipment
- Hazardous area: General purpose
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-1603 |
| Category | Oil & Gas Instruments |
| Group | Instrumentation & Control |
| Brand | The Modal Shop |
| Model | 9100D |
| Technical | |
| Type | Calibration equipment |
| Hazardous area | General purpose |
Datasheet
Technical features
| Self-contained portable shaker for field verification of accelerometers, velocity transducers and proximity probes | |
| Integral quartz reference accelerometer and conditioning electronics for stable control | |
| Carbon-fibre composite armature flexures; rugged shaker element | |
| NIST-traceable verification across a wide frequency and amplitude range | |
| Long battery life with protection against full discharge; mounting adaptors included |
Applications
| Field verification of vibration sensors and monitoring channels | |
| Loop checks of machinery protection systems | |
| Proximity probe and accelerometer calibration checks |
Key specifications
| Frequency range | 7 Hz to 10 kHz (100 g payload) |
|---|---|
| Max. amplitude | 20 g pk (196 m/s²), 380 mm/s pk, 1,270 µm pk-pk at 100 Hz |
| Max. payload | 800 g |
| Accuracy | Acceleration ±3% (30 Hz–2 kHz); velocity ±3% (10 Hz–1 kHz); displacement ±3% (30–150 Hz) |
| Reference | Integral precision quartz accelerometer |
| Case | Pelican Storm case, battery powered |
Specification
| Frequency range | 7 Hz to 10 kHz (operating, 100 g payload) |
|---|---|
| Maximum amplitude | 20 g pk; 15 in/s (380 mm/s) pk; 50 mils (1,270 µm) pk-pk at 100 Hz, no payload |
| Maximum payload | 800 g |
| Readout accuracy | Acceleration ±3% (30 Hz–2 kHz), ±1 dB (7 Hz–10 kHz); velocity ±3% (10 Hz–1 kHz); displacement ±3% (30–150 Hz) |
| Amplitude linearity | < 1% up to 10 g pk (100 g payload, 100 Hz) |
| Waveform distortion | < 5% THD (30 Hz–2 kHz) |
| Accessories | Mounting wrench, power supply and plug adaptors, ¼-28 and 10-32 adaptors, mounting pad; optional mounting kit and transfer-standard reference |
Notes
| Data from the manufacturer's published datasheet. Confirm model, range, materials and approvals with Argonmark before ordering. |
Photo: courtesy of The Modal Shop, used with permission (source) — background removed by Argonmark. All photo credits
Description
The 9100D is a portable, battery-powered shaker table for checking accelerometers, velocity transducers and proximity probes in the field. It vibrates sensors from 7 Hz to 10 kHz at up to 20 g peak (380 mm/s or 1,270 µm pk-pk at 100 Hz) with payloads up to 800 g, controlled by an integral quartz reference accelerometer.
Readout accuracy is ±3% for acceleration, velocity and displacement in their main bands, with NIST-traceable verification. It is built into a rugged Pelican case and comes with mounting adaptors.
Argonmark Ltd supplies The Modal Shop instruments across Bangladesh — Dhaka, Chattogram, Gazipur, Narayanganj and the gas fields, refineries, terminals and power plants beyond. Send us the model, range, process connection, output and any hazardous-area requirement, and we will confirm the right configuration, lead time and price.
