ABB S2C-A1 / S2C-A2 shunt trip for S200 family
Control voltage: 12...60 VAC (12...60 VDC)
2 versions available · full ordering table in the datasheet
Available on order · sourced to your specification
Price on request
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Shunt trip
- Series: S2C-A
- Suitable for: ABB S200, S200P, S200MR and S200MUC supplementary protectors
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-1365 |
| Category | Miniature Circuit Breakers |
| Group | Electrical |
| Brand | ABB |
| Model | S2C-A |
| Technical | |
| Type | Shunt trip |
| Series | S2C-A |
| Suitable for | ABB S200, S200P, S200MR and S200MUC supplementary protectors |
Datasheet
Download manufacturer datasheet (PDF)
ABB S200 series accessories · UL 1077
Ordering information
| Control voltage | Catalogue no. |
|---|---|
| 12...60 VAC (12...60 VDC) | S2C-A1 |
| 110...415 VAC (110...250 VDC) | S2C-A2 |
Technical data
| S2C-A1 | S2C-A2 | ||
|---|---|---|---|
| Rated voltage | AC DC | 12...60 V 12...60 V | 110...415 V 110...250 V |
| Maximum release duration | <10 ms | <10 ms | |
| Minimum release voltage | AC DC | 7 V 10 V | 55 V 80 V |
| Consumption on release | AC DC | 40...200 VA 40...200 VA | 55...210 VA 55...110 VA |
| Coil resistance | 3.7 V | 225 V | |
| Terminals | 18...6/0.75-16 AWG/mm2 | 18...6/0.75-16 AWG/mm2 | |
| Tightening torque | 18/2 in. lbs/Nm | 18/2 in. lbs/Nm |
Compatibility
| Use with | ABB S200, S200P, S200MR and S200MUC supplementary protectors |
|---|
Source: ABB US Catalog, Miniature Circuit Breakers, November 2016 (1SXU400208C0201). Download the series datasheet (PDF)
Description
Shunt trip for remote tripping of the protector when control voltage is applied, field-mountable on the right-hand side.
