Quarter-turn electric actuator EOM10–EOM12, basic, 3500–8000 N·m
Valve Actuators

Quarter-turn electric actuator EOM10–EOM12, basic, 3500–8000 N·m

Part no.
BD-1302
Brand
FLOWINN
Available on order · sourced to your specification
Price on request

Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.

Quick overview

  • Type: Quarter-turn electric
  • Series: EOM
  • Max torque: 3500–8000 N·m
  • Control: On/off
  • Power supply: 1-ph AC110–240V; AC/DC24V
  • Ingress protection: IP67 (optional IP68)
Call +880 1713 552466
  • Genuine productsSourced from the manufacturer or authorised channels
  • Delivery across BangladeshDhaka, Chattogram and all industrial zones
  • After-sales supportInstallation guidance and warranty handling
  • Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com

Specifications

General
Part no.BD-1302
CategoryQuarter-Turn Electric Actuators
GroupValve Actuators
BrandFLOWINN
Technical
TypeQuarter-turn electric
SeriesEOM
Max torque3500–8000 N·m
ControlOn/off
Power supply1-ph AC110–240V; AC/DC24V
Ingress protectionIP67 (optional IP68)
ManufacturerFLOWINN (Shanghai)

Datasheet

FLOWINN EOM series

Technical features

Manufacturer warranty2 years
Overload ProtectionThe power supply is designed to automatically shut off in the event of a valve jam, preventing any further damage to the valve or actuator.
Operational SafetyWith a temperature control switch installed in the motor winding, overheating issues can be prevented and the safe operation of the F-grade insulation motor can be ensured.
Voltage ProtectionBoth high and low voltage situations are taken into account with protective measures implemented to ensure system safety.
Applicable valveBall Valve; Butterfly Valve
Anti-corrosion ProtectionAn enclosure made of epoxy resin that meets NEMA 4X specifications and can be painted to the customer's preference.
Ingress ProtectionIP67 is standard, Optional: IP68( Maximum 7m; Max: 72 hours)
Fireproofing GradeA fire-safe enclosure with the ability to withstand high temperatures, designed to meet a variety of requirements in different situations.

Standard specification

Material of Actuator BodyAluminum Alloy
Control ModeOn-off Type
Torque Range3500-8000N·m
Applicable Voltageone phase:AC110V / AC220V / AC230V /AC240V AC/DC 24V
Ambient Temperature-25°C…..70 °C; Optional: -40°C…..60 °C
Anti-vibration LevelJB/T8219
Noise LevelLess than 75 dB within 1m
Ingress ProtectionIP67, Optional: IP68( Maximum 7m; Max: 72 hours)
Connection SizeISO5211
Motor SpecificationsClass F, with thermal protector up to +135°C (+275°F); Optional : Class H
Working SystemOn-off Type: S2-15 min, no more than 600 times per hour start Optional: 1200 times per hour
On/off type signalInput: AC/DC24V input control or AC110/220V input control. Feedback: valve-closed contact; valve-open contact; optional closing-torque contact and local/remote contacts; integrated fault contact; 4–20 mA transmitter. Malfunction feedback: integrated fault alarm, motor overheating; optional undercurrent protection contact.
Modulating type signalInput 4–20 mA / 0–10 V / 2–10 V; input impedance 250 Ω (4–20 mA). Output 4–20 mA / 0–10 V / 2–10 V; output impedance ≤750 Ω (4–20 mA). Repeatability and linearity within ±1% of full valve stroke. Signal reverse: supported. Loss-of-signal mode setting: supported. Dead zone ≤2.5%.
IndicationPointer indicator
Other functionsPhase correction (3-phase supply only); torque protection; motor overheat protection; moisture-resistant heater

Performance parameters — EFMB / EFM / EOM series

ModelPower (W)Max torque N·m (AC110/220V, AC/DC24V)Max torque N·m (AC220/380V 3-ph)Max torque lbf·in (1-ph)Max torque lbf·in (3-ph)Running time s (AC110/220V 50 Hz)Running time s (AC380V 3-ph 50 Hz)Running time s (AC/DC24V)Running time s (fail-safe)ISO 5211Remarks
EOM10200350035003097530975767655—F14/F16Handwheel, planetary gear
EOM1120050005000442504425010510576—F14/F16Handwheel, planetary gear
EOM12200800080007080070800143143103—F25Handwheel, planetary gear

1. Standard configuration. 2. Rated torque is 75% of the max torque. 3. Motor insulation is class F; class H is optional. 4. Running time at 60 Hz is 5/6 of that at 50 Hz; max output torque is the same. 5. 3-phase output does not apply to EFM1-(H) and EFMA-(H). 6. EOM3A / 7A / 8A / 12: on/off type duty S2-8 min; modulating type S4-15%.

Dimension drawing

EOM dimension drawing

Notes

Data from the manufacturer FLOWINN (Shanghai) Industrial Co., Ltd. Confirm model, torque, voltage and mounting with Argonmark before ordering.

Description

The FLOWINN EOM is a quarter-turn (90°) electric actuator with a planetary-gear handwheel for ball, butterfly and plug valves, covering large valves up to very high torque. This model: max torque 3500–8000 N·m, on/off control, power supply 1-ph AC110–240V; AC/DC24V, IP67 (optional IP68).

Argonmark Ltd supplies FLOWINN electric valve actuators across Bangladesh — Dhaka, Gazipur, Narayanganj, Chattogram and beyond — for power plants, water and effluent treatment plants (WTP/ETP), textile, dyeing and washing plants, chemical, fertiliser, pharmaceutical and food factories, and HVAC and building services. Send us the valve type and size, the torque you need, the power supply and the control signal, and we will confirm the right model, mounting flange and price.
