Linear electric actuator ELM 100–250 series, integral type, up to 25000 N
Pricing depends on specification, quantity and delivery location. Send your requirement and we reply with a costed quotation within 24 hours.
Quick overview
- Type: Linear electric
- Series: ELM
- Max thrust: 1000–25000 N
- Max stroke: 100 mm
- Power supply: 4–240V (as stated by manufacturer)
- Ingress protection: IP67
- Genuine productsSourced from the manufacturer or authorised channels
- Delivery across BangladeshDhaka, Chattogram and all industrial zones
- After-sales supportInstallation guidance and warranty handling
- Reply within 24 hoursCall +880 1713 552466 or email hello@argonmark.com
Specifications
| General | |
|---|---|
| Part no. | BD-1317 |
| Category | Linear Electric Actuators |
| Group | Valve Actuators |
| Brand | FLOWINN |
| Technical | |
| Type | Linear electric |
| Series | ELM |
| Max thrust | 1000–25000 N |
| Max stroke | 100 mm |
| Power supply | 4–240V (as stated by manufacturer) |
| Ingress protection | IP67 |
| Manufacturer | FLOWINN (Shanghai) |
Datasheet
Technical features
| Manufacturer warranty | 2 years |
|---|---|
| Manual Operation | Full range of products are equipped with hand wheel operating mechanism to facilitate the commissioning and emergency manual operation, manual/ electric automatic switching, safe and reliable. |
| Infrared remote control | The intelligent type actuator is able to provide different remote conrol based on different application requirements. Such as portable infrated remote control in ordinary locations and explosion-proof remote control for hazardous locations. |
| Operational Safety | F grade (H grade is optional) insulation motor. The motor windings are equipped with temperature control switches to sense the temperature of the motor and provide over temperature protection, which ensures the operational safety of the motor. |
| Anti-humidity Resistance | Installed with heater inside the actuator used to remove the internal condensation which cause damages to electrical parts. |
| Phase Protection | Phase detection and correction functions avoid the actuator being damaged by connecting to the wrong power phase. |
Standard specification
| Force range | 1000-25000N |
|---|---|
| Max stroke | 100mm |
| Running time | 55-179S |
| Ambient temperature | -25°C---+70°C |
| Anti-vibration level | JB/T 8219 |
| Noise level | Less than 75dB within 1m |
| Electrical interface | Two PG16 |
| Ingress Protection | IP67 |
| Optional | IP68 |
| Motor Specifications | Class F.with thermal protector up to +135°C optional:Class H |
| Working System | On/off type, S2-15min, no more than 600 times per hour start |
| Modulating type | S4-50%, up to 600 triggers per hour |
| Optional | 1200 and 1800 times per hour. |
| Applicable Voltage | 4V-240V |
| Single phase | DC24V2 |
| Bus | Modbus |
| Input signal | On/off type,20-60VAC/DC or 60-120VAC; Optoelectronic isolation; Modulating type. |
| Input signal | 4-20mA; 0-10V; 2-10V;Accuracy 1% |
| Dead zone | 0-25.5% adjustable rate in full stroke. |
| Input impedance | 75Ω (4-20mA) |
| Signal Feedback | On/off |
| Type Relay ×5 | 1.on/off in place;2.on/off over torque; 3.Local/remote;4.Center position;5.Multiple malfuntions to choose from;Optional:4-20mA transmit. |
| Malfunction Feedback | On/off, typeTorqueprotection;Motor, overheat protection;Jammed, valve, protection; Instantaneous, reverse, protection;Broken, signal protection; Other alarms |
| Output Signal | 4-20mA |
| Modulating type | 0-10V |
| Output signal | 2-10V |
| Output impedance | ≤750Ω (4-20mA) |
| Indication | Stroke indicator |
Dimension drawing
Notes
| The supplier publishes performance data only for ELM010–ELM080 (up to 8000 N, 60 mm stroke). Data for the larger 10–25 kN models is available on request. | |
| Data from the manufacturer FLOWINN (Shanghai) Industrial Co., Ltd. Confirm model, torque, voltage and mounting with Argonmark before ordering. |
Description
The FLOWINN ELM is a linear electric actuator for globe valves and control valves, with a handwheel for commissioning and emergency manual operation. This model: max thrust 1000–25000 N, stroke 100 mm, power supply 4–240V (as stated by manufacturer), IP67.
Argonmark Ltd supplies FLOWINN electric valve actuators across Bangladesh — Dhaka, Gazipur, Narayanganj, Chattogram and beyond — for power plants, water and effluent treatment plants (WTP/ETP), textile, dyeing and washing plants, chemical, fertiliser, pharmaceutical and food factories, and HVAC and building services. Send us the valve type and size, the torque you need, the power supply and the control signal, and we will confirm the right model, mounting flange and price.
